Hier vindt u alle beschikbare onderdelen en tekeningen van de 'Hikoki NV65HMC'. Vanaf hier kunt u direct alle gewenste onderdelen bestellen. Vele onderdelen moeten bij de fabrikant besteld worden, dit duurt afhankelijk van het merk, één tot vier weken. Alle informatie die we hebben, staat op onze website, wij kunnen u geen advies geven over wat u nodig heeft, daarvoor zult u de machine ter reparatie in moeten leveren. Let bij het bestellen op het volgende:
Tekeningen van de Hikoki NV65HMC
Onderdelen lijst van de Hikoki NV65HMC
| Pos. | Omschrijving | Prijs excl. BTW | Prijs incl. BTW | |
| Getoonde prijzen zijn inclusief btw | ||||
| Geen informatie beschikbaar, niet bestelbaar | ||||
| 1 | 980046 | |||
| PLATE | ||||
| 2 | 887026 | 5.10 | 6.17 | |
| TOP COVER | ||||
| 3 | 887025 | 5.10 | 6.17 | |
| MUFFLER | ||||
| 4 | 886658 | 5.10 | 6.17 | |
| PROTECTOR | ||||
| 5 | 886423 | 6.75 | 8.17 | |
| NYLOCK BOUT M5X25 | ||||
| 6 | 881262 | 2.70 | 3.27 | |
| EXHAUST COVER | ||||
| 7 | 886421 | 82.36 | 99.66 | |
| HEAD VALVE SPRING | ||||
| 8 | 886418 | 1.80 | 2.18 | |
| O-RING | ||||
| 9 | 883770 | 1.80 | 2.18 | |
| HEAD VALVE | ||||
| 10 | 886416 | 30.25 | 36.60 | |
| O-RING | ||||
| 11 | 886417 | 3.45 | 4.17 | |
| O-RING | ||||
| 12 | 883774 | 3.45 | 4.17 | |
| EXHAUST RUBBER | ||||
| 13 | 886419 | 14.70 | 17.79 | |
| PAKKING | ||||
| 14 | 883789 | 6.75 | 8.17 | |
| O-RING | ||||
| 15 | 883751 | 10.35 | 12.52 | |
| SLAGPEN (H) | ||||
| 16 | 886402 | 100.65 | 121.79 | |
| CYLINDER O-RING (D) | ||||
| 17 | 877126 | 1.65 | 2.00 | |
| SEPERATER | ||||
| 18 | 886420 | 39.74 | 48.08 | |
| O-RING (1AS-50) | ||||
| 19 | 990067 | 1.65 | 2.00 | |
| VALVE RUBBER | ||||
| 20 | 883768 | 9.45 | 11.43 | |
| CYLINDER BUMPER | ||||
| 21 | 883956 | 7.35 | 8.89 | |
| CYLINDER WASHER | ||||
| 22 | 883955 | 6.75 | 8.17 | |
| CYLINDER | ||||
| 23 | 886415 | 140.25 | 169.70 | |
| KNOP (GROEN) | ||||
| 24 | 884334 | 1.65 | 2.00 | |
| RETAININGRING D4 | ||||
| 25 | 968643 | 1.95 | 2.36 | |
| VALVE BUSHING | ||||
| 26 | 885027 | 20.21 | 24.46 | |
| O-RING (S-10) | ||||
| 27 | 987105 | 1.05 | 1.27 | |
| O-RING (S-3) | ||||
| 28 | 881715 | 1.05 | 1.27 | |
| O-RING (1AP-3) | ||||
| 29 | 873093 | 1.05 | 1.27 | |
| Plunger | ||||
| 30 | 885028 | 18.29 | 22.13 | |
| SLAGPIN (OUD 885028) | ||||
| 30A | 886044 | 18.29 | 22.13 | |
| O-RING | ||||
| 31 | 878607 | 1.05 | 1.27 | |
| VEER | ||||
| 32A | 887177 | 1.20 | 1.45 | |
| PAKKING (OLD 881711) | ||||
| 33 | 884338 | 1.05 | 1.27 | |
| O-RING (P-36) | ||||
| 34 | 931835 | 1.65 | 2.00 | |
| O-RING (P-32) | ||||
| 35 | 986374 | 1.65 | 2.00 | |
| RING VOOR SCHACHT | ||||
| 36 | 886669 | 1.80 | 2.18 | |
| RETAININGRING D4 | ||||
| 36A | 968643 | 1.95 | 2.36 | |
| WARNING LABEL (A) | ||||
| 38 | 883513 | 1.65 | 2.00 | |
| BODY ASS'Y | ||||
| 39 | 887173 | 134.20 | 162.38 | |
| HIKOKI NAAMPLAAT | ||||
| 40 | 886342 | 1.80 | 2.18 | |
| HIKOKI NAAMPLAAT | ||||
| 40A | 886342 | 1.80 | 2.18 | |
| SLAGPEN BUMPER | ||||
| 41 | 885195 | 6.75 | 8.17 | |
| O-RING (S-38) | ||||
| 42 | 980717 | 1.35 | 1.63 | |
| NOSE | ||||
| 43 | 886403 | 256.03 | 309.79 | |
| CHANGE KNOB | ||||
| 44 | 886409 | 3.45 | 4.17 | |
| LOCK SPRING | ||||
| 45 | 882923 | 1.80 | 2.18 | |
| STALEN KOGEL D3.175 (10 STUKS) | ||||
| 46 | 959148 | 1.05 | 1.27 | |
| NAALDROLLER | ||||
| 47 | 880659 | 1.05 | 1.27 | |
| ROL PIN D4X18 (10 STUKS) | ||||
| 48 | 949498 | 1.74 | 2.11 | |
| FEEDER ARM (B) | ||||
| 49 | 883144 | 46.75 | 56.57 | |
| VEER VOOR TOEVOERMECHANISME | ||||
| 50 | 883143 | 1.65 | 2.00 | |
| FEEDER (A) | ||||
| 51 | 886406 | 26.26 | 31.78 | |
| NYLOCK HIGH TENSION BOUT M6X20 | ||||
| 52 | 880675 | 4.05 | 4.90 | |
| NAIL GUIDE SHAFT | ||||
| 53 | 883755 | 7.35 | 8.89 | |
| PUSHING LEVER COVER (A) | ||||
| 54 | 883761 | 5.10 | 6.17 | |
| PUSHING LEVER (A) | ||||
| 55 | 887024 | 67.10 | 81.19 | |
| NEUS KAP | ||||
| 56 | 886650 | 3.45 | 4.17 | |
| NYLON MOER M5 | ||||
| 57 | 877371 | 1.05 | 1.27 | |
| O-RING (I.D. 37.2) | ||||
| 59 | 880183 | 1.05 | 1.27 | |
| CAP (GOLD) | ||||
| 60 | 886426 | 20.21 | 24.46 | |
| STOFKAPJE | ||||
| 61 | 877914 | 1.95 | 2.36 | |
| AIR PLUG L-PT 1/4 | ||||
| 62 | 883135 | 14.99 | 18.13 | |
| MACHINE SCREW M5X25 BLACK (W/WASHER) | ||||
| 64 | 887315 | 1.80 | 2.18 | |
| ROL PIN D3X28 (10 STUKS) | ||||
| 65 | 949865 | 2.55 | 3.09 | |
| TRIGGER PIECE (C) | ||||
| 66 | 886626 | 1.80 | 2.18 | |
| TRIGGER SPRING | ||||
| 67 | 886627 | 1.80 | 2.18 | |
| SCHAKELAAR | ||||
| 69 | 886623 | 3.45 | 4.17 | |
| TRIGGER (S) | ||||
| 69A | 886052 | 9.00 | 10.89 | |
| TRIGGGER SPRING | ||||
| 70 | 883759 | 3.30 | 3.99 | |
| TRIGGER SPRING | ||||
| 70A | 884916 | 1.80 | 2.18 | |
| PUSHING LEVER GUIDE | ||||
| 71 | 886047 | 18.29 | 22.13 | |
| PUSHING LEVER SPRING | ||||
| 72 | 882892 | 5.10 | 6.17 | |
| PUSHING LEVER (C) | ||||
| 73 | 882891 | 18.15 | 21.96 | |
| ADJUSTER | ||||
| 74 | 882889 | 3.45 | 4.17 | |
| ROLL PIN D1.6X10 | ||||
| 75 | 886228 | 1.80 | 2.18 | |
| ROL PIN D2.5X16 | ||||
| 76 | 881951 | 1.80 | 2.18 | |
| ROL PIN D2X16 | ||||
| 77 | 880093 | 1.04 | 1.26 | |
| STALEN KOGEL D3.175 (10 STUKS) | ||||
| 78 | 959148 | 1.05 | 1.27 | |
| LOCK SPRING | ||||
| 79 | 882923 | 1.80 | 2.18 | |
| LOCK KNOB | ||||
| 80 | 886727 | 3.45 | 4.17 | |
| LOCK KNOB | ||||
| 80A | 885865 | 18.70 | 22.63 | |
| ADJUSTER SPRING | ||||
| 81 | 882890 | 1.65 | 2.00 | |
| ADJUSTER PLATE | ||||
| 82 | 884973 | 1.65 | 2.00 | |
| ADJUSTER PLATE | ||||
| 83 | 882886 | 3.30 | 3.99 | |
| O-RING (S-4) | ||||
| 84 | 981317 | 1.05 | 1.27 | |
| PUSHING LEVER (B) | ||||
| 85 | 882888 | 17.33 | 20.96 | |
| O-RING (S-5) | ||||
| 86 | 872822 | 3.00 | 3.63 | |
| STOPRING | ||||
| 87 | 872971 | 1.05 | 1.27 | |
| O-RING (P9-U) | ||||
| 88 | 883104 | 3.45 | 4.17 | |
| VALVE PISTON | ||||
| 89 | 883101 | 30.25 | 36.60 | |
| O-RING (1AP-11) | ||||
| 90 | 878764 | 1.04 | 1.26 | |
| PLUNGER SPRING | ||||
| 91 | 883103 | 1.80 | 2.18 | |
| O-RING (I.D. 1.8) | ||||
| 92 | 883405 | 5.10 | 6.17 | |
| PLUNGER (S) | ||||
| 93B | 886051 | 55.00 | 66.55 | |
| PIN D2X8 (10 PCS) | ||||
| 94 | 949778 | 1.80 | 2.18 | |
| O-RING (S-14) | ||||
| 95 | 876319 | 1.65 | 2.00 | |
| O-RING (S-16) | ||||
| 96 | 876031 | 1.65 | 2.00 | |
| VALVE BUSHING (B) | ||||
| 97 | 886042 | 15.95 | 19.30 | |
| O-RING (P7-U) | ||||
| 98 | 883105 | 3.45 | 4.17 | |
| O-RING (1AP-5) | ||||
| 99 | 873407 | 1.04 | 1.26 | |
| O-RING (S-6) | ||||
| 100 | 997218 | 1.05 | 1.27 | |
| VALVE BUSHING (A) | ||||
| 101 | 883099 | 8.10 | 9.80 | |
| O-RING (1AP-3) | ||||
| 102 | 873093 | 1.05 | 1.27 | |
| O-RING (P-9) | ||||
| 103 | 872645 | 1.65 | 2.00 | |
| FEED PISTON O-RING (I.D.14) | ||||
| 104 | 877763 | 1.05 | 1.27 | |
| FEED PISTON | ||||
| 105A | 887455 | 22.00 | 26.62 | |
| FEED SPRING (A) | ||||
| 106 | 883757 | 1.80 | 2.18 | |
| FEED SPRING (B) | ||||
| 107 | 883758 | 1.80 | 2.18 | |
| BUMPER | ||||
| 108 | 885681 | 7.35 | 8.89 | |
| FEED PISTON COVER | ||||
| 109 | 883098 | 3.45 | 4.17 | |
| BORGRING VOOR D24 | ||||
| 110 | 983748 | 1.05 | 1.27 | |
| BOUT HD M5X20 (10 STUKS) | ||||
| 111 | 949757 | 3.00 | 3.63 | |
| RING VOOR SCHACHT | ||||
| 112 | 880319 | 1.65 | 2.00 | |
| O-RING (P-4) | ||||
| 113 | 874436 | 1.05 | 1.27 | |
| SPRING | ||||
| 114 | 886412 | 1.80 | 2.18 | |
| NOSE SHAFT | ||||
| 115 | 886410 | 5.10 | 6.17 | |
| NOSE PIECE | ||||
| 116 | 886652 | 27.50 | 33.28 | |
| NAIL GUIDE COVER | ||||
| 117 | 883784 | 4.80 | 5.81 | |
| COVER | ||||
| 118A | 888131 | 1.80 | 2.18 | |
| GUIDE LOCK NV50AE | ||||
| 119 | 886107 | 5.10 | 6.17 | |
| VEER (OUD 878308) | ||||
| 120 | 880446 | 1.35 | 1.63 | |
| NAIL GUIDE | ||||
| 121 | 886404 | 61.05 | 73.87 | |
| NAIL STOPPER (A) | ||||
| 122 | 883783 | 67.79 | 82.02 | |
| NAIL STOPPER SPRING | ||||
| 123 | 886451 | 1.80 | 2.18 | |
| NAIL STOPPER | ||||
| 124 | 882680 | 3.30 | 3.99 | |
| VEER | ||||
| 125 | 880494 | 2.40 | 2.90 | |
| NYLOCK HEX. SOCKET HD.BOLT M4X10 | ||||
| 126 | 880413 | 1.05 | 1.27 | |
| SLEEVE (B) | ||||
| 127 | 882881 | 3.30 | 3.99 | |
| INBUSBOUT HD M4X12 | ||||
| 128 | 880630 | 1.05 | 1.27 | |
| WAARSCHUWINGS LABEL | ||||
| 129 | 887175 | 5.10 | 6.17 | |
| WAARSCHUWINGS LABEL | ||||
| 131 | 887174 | 5.10 | 6.17 | |
| MAGAZINE | ||||
| 132 | 886428 | 13.35 | 16.15 | |
| SLEEVE | ||||
| 133 | 882907 | 3.30 | 3.99 | |
| PUSHING LEVER COVER (B) | ||||
| 134 | 883762 | 6.75 | 8.17 | |
| PIN | ||||
| 135 | 881825 | 3.00 | 3.63 | |
| RING VOOR SCHACHT | ||||
| 136 | 877826 | 2.55 | 3.09 | |
| MAGAZINE COVER | ||||
| 137 | 883926 | 16.36 | 19.80 | |
| RATCHET SPRING | ||||
| 140 | 880398 | 7.65 | 9.26 | |
| HOLDER CAP (A) | ||||
| 141 | 881003 | 2.40 | 2.90 | |
| NAIL RAIL (OLD 882906) | ||||
| 142 | 885683 | 24.75 | 29.95 | |
| NAIL RAIL (OLD 882906) | ||||
| 142A | 885683 | 24.75 | 29.95 | |
| ROL PIN D2.5X12 | ||||
| 143 | 878791 | 1.04 | 1.26 | |
| Geen informatie beschikbaar, niet bestelbaar | ||||
| 144 | 882905 | |||
| HOLDER SHAFT (OLD 882905) | ||||
| 144A | 889509 | 1.80 | 2.18 | |
| SPRING | ||||
| 145 | 881826 | 1.05 | 1.27 | |
| MAGAZINE ASS'Y | ||||
| 146 | 887314 | 82.36 | 99.66 | |
| TRIGGER PARTS SET (OLD 886621+886624+886625) | ||||
| 147 | 888727 | 17.33 | 20.96 | |
| O-RING (I.D. 1.8) | ||||
| 148 | 883405 | 5.10 | 6.17 | |
| TRIGGER PIN | ||||
| 149 | 885268 | 13.05 | 15.79 | |
| VEERRING | ||||
| 150 | 886056 | 1.50 | 1.82 | |
| VEER | ||||
| 151 | 886054 | 14.16 | 17.14 | |
| TRIGGER ARM (S) | ||||
| 152 | 886053 | 161.56 | 195.49 | |
| TRIGGER ARM PIN | ||||
| 153 | 886055 | 22.00 | 26.62 | |
| Geen informatie beschikbaar, niet bestelbaar | ||||
| 501 | 883136 | |||
| Geen informatie beschikbaar, niet bestelbaar | ||||
| 502 | 875769 | |||
| Niet meer leverbaar, geen vervanging | ||||
| 503 | 886432 | |||
| Geen informatie beschikbaar, niet bestelbaar | ||||
| 503A | 888666 | |||
| GRIP TAPE (OLD 880349) | ||||
| 601 | 881768 | 5.25 | 6.35 | |
| Geen informatie beschikbaar, niet bestelbaar | ||||
| 602A | 888213 | |||
| Geen informatie beschikbaar, niet bestelbaar | ||||
| 603 | 876212 | |||
| SINGLE SEQUENTIAL ACTUATION MECHANISM KIT | ||||
| 604 | 887952 | 329.18 | 398.30 | |
