Hier vindt u alle beschikbare onderdelen en tekeningen van de 'Hikoki RP3608DBW4Z'. Vanaf hier kunt u direct alle gewenste onderdelen bestellen. Vele onderdelen moeten bij de fabrikant besteld worden, dit duurt afhankelijk van het merk, één tot vier weken. Alle informatie die we hebben, staat op onze website, wij kunnen u geen advies geven over wat u nodig heeft, daarvoor zult u de machine ter reparatie in moeten leveren. Let bij het bestellen op het volgende:
Tekeningen van de Hikoki RP3608DBW4Z
Onderdelen lijst van de Hikoki RP3608DBW4Z
| Pos. | Omschrijving | Prijs excl. BTW | Prijs incl. BTW | |
| Getoonde prijzen zijn inclusief btw | ||||
| POWDER FILTER 8-15L | ||||
| 1 | 337460 | 43.73 | 52.91 | |
| TEXTIEL FILTER | ||||
| 2 | 337462 | 6.60 | 7.99 | |
| FILTER DAMPER | ||||
| 3 | 337463 | 8.25 | 9.98 | |
| VOORFILTER 8-15L | ||||
| 4 | 337465 | 33.55 | 40.60 | |
| DOPMOER M4 | ||||
| 5 | 311839 | 1.05 | 1.27 | |
| VEERRING M4 (10 STUKS) | ||||
| 6 | 949453 | 1.05 | 1.27 | |
| RING M4 (10 STUKS) | ||||
| 7 | 949423 | 1.05 | 1.27 | |
| MACHINESCHROEF M4X14 (10 STUKS) | ||||
| 8 | 949218 | 1.05 | 1.27 | |
| TANK ASS'Y (8L) | ||||
| 9 | 373591 | 71.50 | 86.52 | |
| DOPMOER M8 | ||||
| 10 | 975597 | 1.05 | 1.27 | |
| RING M8 (10 STUKS) | ||||
| 11 | 949433 | 1.05 | 1.27 | |
| SLANGAANSLUITSTUK | ||||
| 12 | 337451 | 5.55 | 6.72 | |
| ONTGRENDELING VOOR SLANG | ||||
| 13 | 321014 | 1.65 | 2.00 | |
| VOORDEKSEL | ||||
| 14 | 337449 | 2.10 | 2.54 | |
| AFDICHTING | ||||
| 15 | 339182 | 2.40 | 2.90 | |
| STOOTRAND | ||||
| 16 | 337446 | 11.55 | 13.98 | |
| Earth Chain | ||||
| 17 | 329872 | 1.80 | 2.18 | |
| MOER M4 ( 10 STUKS ) | ||||
| 18 | 949554 | 1.05 | 1.27 | |
| ZWENKWIEL KOMPLEET | ||||
| 19 | 337438 | 2.55 | 3.09 | |
| Rubberen Ring | ||||
| 20 | 338453 | 1.05 | 1.27 | |
| CASTER HOLDER | ||||
| 21 | 338454 | 1.04 | 1.26 | |
| Zwenkwiel Kompleet + Rem | ||||
| 22 | 337439 | 3.00 | 3.63 | |
| SPECIAL NUT | ||||
| 23 | 373590 | 2.70 | 3.27 | |
| WASHER | ||||
| 24 | 374772 | 1.04 | 1.26 | |
| POLY GUIDE | ||||
| 25 | 337452 | 1.65 | 2.00 | |
| AARDPLAATJE | ||||
| 26 | 337454 | 1.04 | 1.26 | |
| INTERNAL WIRE | ||||
| 27 | 329183 | 3.15 | 3.81 | |
| TAPSCHROEF D4X25 MET RING ZWART | ||||
| 28 | 307028 | 1.05 | 1.27 | |
| SPECIAL BOLT | ||||
| 29 | 373589 | 1.80 | 2.18 | |
| KLEMBEUGEL | ||||
| 30 | 337455 | 4.80 | 5.81 | |
| MACHINESCHROEF M4X16 (10 STUKS) | ||||
| 31 | 949219 | 1.20 | 1.45 | |
| SLEEVE (B) ID28 | ||||
| 32 | 338478 | 1.35 | 1.63 | |
| HOSE ASS'Y ID28 | ||||
| 33 | 374775 | 31.63 | 38.27 | |
| CLICK RING (FOR D28) | ||||
| 34 | 337515 | 1.05 | 1.27 | |
| SCREW RING (ID 28) | ||||
| 35 | 337514 | 1.05 | 1.27 | |
| SLEEVE (A) ID38 | ||||
| 36 | 374776 | 1.20 | 1.45 | |
| MOTOR ASS'Y | ||||
| 37 | 373569 | 121.55 | 147.08 | |
| RUBBER RING | ||||
| 38 | 338928 | 1.04 | 1.26 | |
| STATOR FET PCB | ||||
| 39 | 341051 | 56.10 | 67.88 | |
| FAN BASE | ||||
| 40 | 373573 | 7.20 | 8.71 | |
| ROTOR | ||||
| 41 | 361091 | 43.31 | 52.41 | |
| KOGELLAGER 608VV | ||||
| 42 | 333945 | 1.80 | 2.18 | |
| BEARING HOLDER | ||||
| 43 | 339180 | 1.04 | 1.26 | |
| FLANGE WASHER | ||||
| 44 | 339174 | 1.05 | 1.27 | |
| FAN | ||||
| 45 | 339166 | 3.00 | 3.63 | |
| CASING | ||||
| 46 | 339177 | 3.00 | 3.63 | |
| SPECIAL WASHER | ||||
| 47 | 339178 | 1.04 | 1.26 | |
| LOCK NUT M8 | ||||
| 48 | 339175 | 1.04 | 1.26 | |
| DRAAG RING (B) | ||||
| 49 | 334977 | 13.75 | 16.64 | |
| SILENT FILTER (H) | ||||
| 50 | 374771 | 1.35 | 1.63 | |
| STILLE FILTER (a) | ||||
| 51 | 337475 | 1.04 | 1.26 | |
| MOTOR BASE ASS'Y | ||||
| 52 | 373897 | 22.55 | 27.29 | |
| TAPSCHROEF D4X45 MET RING | ||||
| 53 | 301815 | 1.05 | 1.27 | |
| GUARD PLATE | ||||
| 54 | 338484 | 1.20 | 1.45 | |
| SCREW (PLASTIC TIE) D4X16 | ||||
| 55 | 994810 | 1.05 | 1.27 | |
| DISPLAYPLAAT (D) | ||||
| 57 | 373902 | 4.80 | 5.81 | |
| SWITCH HOLDER | ||||
| 58 | 373901 | 24.34 | 29.45 | |
| SWITCH COVER | ||||
| 59 | 373576 | 1.04 | 1.26 | |
| SWITCH PACKING | ||||
| 60 | 373578 | 1.04 | 1.26 | |
| SWITCH | ||||
| 61 | 373577 | 13.80 | 16.70 | |
| Beschermschuim | ||||
| 63 | 370077 | 1.04 | 1.26 | |
| TAPSCHROEF D3X12 MET RING | ||||
| 64 | 372288 | 1.20 | 1.45 | |
| CONTROLLER MAIN ASS'Y | ||||
| 65 | 373895 | 168.16 | 203.48 | |
| CONNECTOR | ||||
| 66 | 374773 | 1.05 | 1.27 | |
| Geen informatie beschikbaar, niet bestelbaar | ||||
| 67 | 371750 | |||
| BATTERY GUARD ASS'Y | ||||
| 68 | 373572 | 20.76 | 25.12 | |
| CLAMP LEVER (A) | ||||
| 69 | 373613 | 1.04 | 1.26 | |
| CLAMP SPRING | ||||
| 70 | 373610 | 1.04 | 1.26 | |
| CORD COVER | ||||
| 71 | 373607 | 1.20 | 1.45 | |
| HANDLE | ||||
| 72 | 373604 | 6.45 | 7.80 | |
| BATTERIJ CONTACTPUNT HOUDER | ||||
| 73 | 373605 | 3.30 | 3.99 | |
| HEAD COVER ASS'Y | ||||
| 74 | 373896 | 21.59 | 26.12 | |
| HEAD COVER PACKING (A) | ||||
| 76 | 373898 | 2.25 | 2.72 | |
| HEAD COVER PACKING (C) | ||||
| 77 | 373602 | 1.04 | 1.26 | |
| HEAD COVER PACKING (D) | ||||
| 78 | 373603 | 1.04 | 1.26 | |
| HEAD COVER PACKING (C) NEW | ||||
| 79 | 373601 | 1.05 | 1.27 | |
| HEAD COVER PACKING (B) NEW | ||||
| 80 | 373600 | 1.35 | 1.63 | |
| SILENT FILTER (D) | ||||
| 81 | 373619 | 1.20 | 1.45 | |
| SILENT FILTER (C) | ||||
| 82 | 373616 | 1.04 | 1.26 | |
| SILENT FILTER (B) | ||||
| 83 | 373615 | 1.04 | 1.26 | |
| SILENT FILTER (L) | ||||
| 84 | 373626 | 1.20 | 1.45 | |
| MOTOR COVER | ||||
| 85 | 373597 | 17.60 | 21.30 | |
| SILENT FILTER (F) NEW | ||||
| 86 | 373623 | 1.04 | 1.26 | |
| SILENT FILTER (E) | ||||
| 87 | 373621 | 1.04 | 1.26 | |
| MOTOR PACKING (A) | ||||
| 88 | 373596 | 3.45 | 4.17 | |
| SILENT FILTER (J) | ||||
| 89 | 373625 | 1.04 | 1.26 | |
| SILENT FILTER (M) | ||||
| 90 | 373624 | 1.04 | 1.26 | |
| SILENT FILTER (C) | ||||
| 91 | 373617 | 1.04 | 1.26 | |
| SILENT FILTER (D) | ||||
| 92 | 373618 | 1.04 | 1.26 | |
| SILENT FILTER (A) | ||||
| 93 | 373614 | 1.04 | 1.26 | |
| SILENT FILTER (E) | ||||
| 94 | 373620 | 1.04 | 1.26 | |
| SILENT FILTER (F) | ||||
| 95 | 373622 | 1.04 | 1.26 | |
| PAKKING (A) | ||||
| 96 | 373570 | 1.04 | 1.26 | |
| TAPSCHROEF D4X35 MET RING ZWART | ||||
| 97 | 303694 | 1.04 | 1.26 | |
| TAPSCHROEF D4X20 MET RING ZWART (OUD 305095) | ||||
| 98 | 301653 | 1.04 | 1.26 | |
| BEHUIZING | ||||
| 99 | 338902 | 6.30 | 7.62 | |
| RING | ||||
| 100 | 372734 | 1.04 | 1.26 | |
| HULPSTUKKEN HOUDER | ||||
| 501 | 373588 | 9.30 | 11.25 | |
| BESCHERMKAPJE VOOR BATTERIJ | ||||
| 503 | 329897 | 1.80 | 2.18 | |
| Geen informatie beschikbaar, niet bestelbaar | ||||
| 504A | 375679 | |||
| VERLOOPSTUK (A) | ||||
| 505 | 337524 | 1.04 | 1.26 | |
| Geen informatie beschikbaar, niet bestelbaar | ||||
| 506 | 337527 | |||
