Hikoki THB260PF tekeningen en onderdelen

Zoek naar onderdelen:
Hikoki
Exact typenummer:
THB260PF

Tekeningen van de HIKOKI THB260PF

Onderdelen lijst van de HIKOKI THB260PF

Op deze pagina kunt u onderdelen toevoegen aan de winkelwagen, door het aantal te selecteren en daarna de knop erachter te klikken. Wanneer u klaar bent met het uitzoeken van de juiste onderdelen, kunt u onder aan de pagina op de knop "Uw winkelwagen" klikken. De prijzen hieronder zijn inclusief btw. Het exacte btw bedrag wordt in de winkelwagen berekend op basis van het land waarin u het pakket wenst te ontvangen.
Air Cleaner Body
16684856Air Cleaner Body€ 14.37
Choke Valve (oud 493-06590-20)
26684857Choke Valve (oud 493-06590-20)€ 9.90
Collar (old 470-0602k-20)
36684858Collar (old 470-0602k-20)€ 4.15
Spacer (oud 453-0602k-20)
46684859Spacer (oud 453-0602k-20)€ 2.08
Blow Over Check Board (old 476-0634c-20)
56684860Blow Over Check Board (old 476-0634c-20)€ 4.15
Reinigingsspons (oud 446-0634c-20)
66684861Reinigingsspons (oud 446-0634c-20)€ 9.10
Cleaner Cap (oud 424-06590-20)
76684862Cleaner Cap (oud 424-06590-20)€ 4.15
Air Cleaner Ass'y (oud 410-06590-91)
86684863Air Cleaner Ass'y (oud 410-06590-91)€ 19.32
Ring 5 (oud 992-00050-011)
96684864Ring 5 (oud 992-00050-011)€ 2.08
Ring (oud 992-10050-012)
106684662Ring (oud 992-10050-012)€ 2.08
Screw M5x60 (oud 990-11050-602)
116684660Screw M5x60 (oud 990-11050-602)€ 2.08
Niet meer leverbaar
126684865Niet meer leverbaar
Partition Plate (oud 132-07550-20)
136684866Partition Plate (oud 132-07550-20)€ 4.15
Insulator Set (oud 404-07550-90)
146684867Insulator Set (oud 404-07550-90)€ 11.18
Hex. Hole Bolt 5x25/ws (oud 994-64050-25)
156684617Hex. Hole Bolt 5x25/ws (oud 994-64050-25)€ 2.08
Carburetor Gasket (oud 402-07550-20)
166684868Carburetor Gasket (oud 402-07550-20)€ 3.78
Cable Adjuster (oud 614-25137-20)
196684871Cable Adjuster (oud 614-25137-20)€ 4.15
Lock Nut M6 (oud 991-01060-013)
206684872Lock Nut M6 (oud 991-01060-013)€ 2.08
Swivel (oud 539-25120-20)
226684697Swivel (oud 539-25120-20)€ 6.23
Stop Ring (oud 489-25100-20)
246684696Stop Ring (oud 489-25100-20)€ 2.08
O-RING (OUD 550-25100-20)
266684695O-RING (OUD 550-25100-20)€ 4.15
Pump Gasket (old 577-25292-20 & 6696321)
286684692Pump Gasket (old 577-25292-20 & 6696321)€ 28.25
Diaphragm Gasket (oud 475-25153-20)
296684691Diaphragm Gasket (oud 475-25153-20)€ 8.30
Priming Body (oud 447-25108-20)
316684689Priming Body (oud 447-25108-20)€ 6.23
Diaphragm Cover (oud 476-25151-20)
326684688Diaphragm Cover (oud 476-25151-20)€ 8.30
Pump Diaphragm (old 576-25100-20 & 6696325)
336684693Pump Diaphragm (old 576-25100-20 & 6696325)€ 8.30
Inlet Screen (oud 578-25007-20)
346684700Inlet Screen (oud 578-25007-20)€ 4.15
Pump Body Comp. (old 575-25153-80)
356684879Pump Body Comp. (old 575-25153-80)€ 60.17
Metering Diaphragm (old 474-25601-20)
366684690Metering Diaphragm (old 474-25601-20)€ 17.42
Set Screw (old 548-25151-20 & 6696324)
376684699Set Screw (old 548-25151-20 & 6696324)€ 2.08
Fuel Pipe Ass'y (oud 223-0097a-90)
386684618Fuel Pipe Ass'y (oud 223-0097a-90)€ 4.15
Fuel Pipe 3x5x80 (oud 700-03005-08)
396684880Fuel Pipe 3x5x80 (oud 700-03005-08)€ 2.08
Return Grommet (old 6684627)
40A6697846Return Grommet (old 6684627)€ 1.00
Clip.6.3 Dia. (old 680-00731-20)
416684619Clip.6.3 Dia. (old 680-00731-20)€ 2.08
Niet meer leverbaar
42A6684620Niet meer leverbaar
Carburateurset
436684881Carburateurset€ 64.28
Carburateurset
436684882Carburateurset€ 68.07
Swivel Cap (old 560-07120-21/6684628)
446691337Swivel Cap (old 560-07120-21/6684628)€ 1.11
Throttle Valve Comp. (old 488-25145-80)
456684883Throttle Valve Comp. (old 488-25145-80)€ 18.15
Throttle Set Screw (old 548-25140-20)
466684698Throttle Set Screw (old 548-25140-20)€ 4.15
Wire Set Plate (old 878-07550-20)
476684884Wire Set Plate (old 878-07550-20)€ 1.11
Cleaner Gasket (old 431-07550-20)
486684885Cleaner Gasket (old 431-07550-20)€ 1.11
Hex. Hole Bolt M6x55 (old 990-51060-553/6696819)
496684638Hex. Hole Bolt M6x55 (old 990-51060-553/6696819)€ 2.08
Ring
506684639Ring€ 2.08
Muffler Comp. (old 706-07552-80)
516684887Muffler Comp. (old 706-07552-80)€ 16.40
Insulator (old 133-07550-20)
526684888Insulator (old 133-07550-20)€ 19.32
Screw M4x8/ws (old 994-36040-081)
536684651Screw M4x8/ws (old 994-36040-081)€ 2.08
Spark Arrester (oud 732-07550-20)
546684889Spark Arrester (oud 732-07550-20)€ 4.15
Muffler Special Gasket(old 751-07550-20)
556684890Muffler Special Gasket(old 751-07550-20)€ 1.89
Tail Pipe Set (old 734-07550-90)
566684891Tail Pipe Set (old 734-07550-90)€ 8.30
Hex.hole Bolt M4x18/ws (oud 994-64040-184)
576684599Hex.hole Bolt M4x18/ws (oud 994-64040-184)€ 2.08
Niet meer leverbaar
586684892Niet meer leverbaar
Stop Cord 145l(old 178-07550-80)
596684893Stop Cord 145l(old 178-07550-80)€ 2.08
Plug Cap Ass'y (oud 157-01680-90)
606684894Plug Cap Ass'y (oud 157-01680-90)€ 8.30
Bobine (oud 6684895)
61A6697896Bobine (oud 6684895)€ 17.84
Ring (old 182-0186a-20)
626684600Ring (old 182-0186a-20)€ 2.08
Hex.hole Bolt M5x18/s(oud 994-61050-184)
636684586Hex.hole Bolt M5x18/s(oud 994-61050-184)€ 2.08
Bougie Bmr7a
64A6699316Bougie Bmr7a€ 8.63
Cylinder Gasket (oud 017-07350-20)
656684896Cylinder Gasket (oud 017-07350-20)€ 2.08
Cylinder Set(old 001-07600-90)
666684897Cylinder Set(old 001-07600-90)€ 75.25
Piston Ring (oud 041-01601-20)
676684588Piston Ring (oud 041-01601-20)€ 8.30
Piston Pin Circlip (old 039-00601-20)
686684590Piston Pin Circlip (old 039-00601-20)€ 2.08
Piston Set (old 030-07500-90)
696684898Piston Set (old 030-07500-90)€ 33.09
Piston Pin (old 037-07045-20)
706684591Piston Pin (old 037-07045-20)€ 4.15
Woodruff Key 3x13x4.5 (oud 068-10100-20)
716684899Woodruff Key 3x13x4.5 (oud 068-10100-20)€ 2.08
Niet meer leverbaar
726684900Niet meer leverbaar
Special Bolt (old 025-07550-21/6684901)
736695852Special Bolt (old 025-07550-21/6684901)€ 9.58
Ring M8 (old 992-01080-011)
746684611Ring M8 (old 992-01080-011)€ 2.08
Magneto Rotor
75A6600925Magneto Rotor€ 12.05
Hex.hole Bolt M5x16/s (old 994-61050-164)
766684903Hex.hole Bolt M5x16/s (old 994-61050-164)€ 2.08
Crank Case Gasket(old 090-07350-22)
776684904Crank Case Gasket(old 090-07350-22)€ 2.08
Olie Keerring
786684607Olie Keerring€ 4.15
Kogellager 6001 C3
796684608Kogellager 6001 C3€ 3.68
Gear Shaft Shim 0.20 (oud 330-00200-23)
806684604Gear Shaft Shim 0.20 (oud 330-00200-23)€ 2.08
Gear Shaft Shim 0.30 (oud 330-00200-24)
806684605Gear Shaft Shim 0.30 (oud 330-00200-24)€ 2.08
Main Jet #37 (old 599-2000w-37)
826684877Main Jet #37 (old 599-2000w-37)€ 3.19
Main Jet #39 (old 599-2000w-39) New
826684878Main Jet #39 (old 599-2000w-39) New€ 4.31
Cleaner Body Ass'y (old 423-06590-91) New
846697054Cleaner Body Ass'y (old 423-06590-91) New€ 9.87
Niet meer leverbaar
8866A0466Niet meer leverbaar
Niet meer leverbaar
8966A0475Niet meer leverbaar
Fan Headed Pipe (old 273-31870-20)
1216684906Fan Headed Pipe (old 273-31870-20)€ 18.15
Straight Pipe (old 269-31870-20)
1226684907Straight Pipe (old 269-31870-20)€ 15.08
Throttle Wire 245+93 (old 885-31873-80)
1236684909Throttle Wire 245+93 (old 885-31873-80)€ 3.19
Throttle Lever (old 013-31870-20)
1246684910Throttle Lever (old 013-31870-20)€ 2.08
Stop Switch Comp. (old 170-31870-80)
1256684911Stop Switch Comp. (old 170-31870-80)€ 11.18
Protection Sheet (old 459-31870-20)
1266684912Protection Sheet (old 459-31870-20)€ 2.08
Screw 3x10 (old 994-31030-101)
1276684913Screw 3x10 (old 994-31030-101)€ 2.08
Stop Button (red)
128A6698995Stop Button (red)€ 1.00
Stop Switch Mark (old 925-31870-20)
1296684915Stop Switch Mark (old 925-31870-20)€ 3.78
Muffler Protector (old 738-31870-20)
1306684916Muffler Protector (old 738-31870-20)€ 27.53
Tapschroef D5x20 Zwart
131302089Tapschroef D5x20 Zwart€ 1.02
Machine Screw (w/washers) M5x25 (old 6695424)
132317751Machine Screw (w/washers) M5x25 (old 6695424)€ 2.61
Cruise Lever (old 249-31870-20)
1336684917Cruise Lever (old 249-31870-20)€ 2.08
Ring M5 (oud 992-01050-061)
1346684918Ring M5 (oud 992-01050-061)€ 2.08
Nylon Nut M5 (old 991-78050-010)
135305491Nylon Nut M5 (old 991-78050-010)€ 1.60
Kroonsteentje
136938307Kroonsteentje€ 2.06
Support Handle (old 424-31870-20)
1376684919Support Handle (old 424-31870-20)€ 9.90
Tapschroef D5x20 Zwart
138302089Tapschroef D5x20 Zwart€ 1.02
Cover Setting Bolt (old 450-31870-80)
1396684920Cover Setting Bolt (old 450-31870-80)€ 8.30
Guard Net (old 050-31870-20)
1406684921Guard Net (old 050-31870-20)€ 15.08
Micro Switch (old 509-31874-90)
1416684922Micro Switch (old 509-31874-90)€ 13.26
Volute Case (old 052-31870-21/6684923)
1426696390Volute Case (old 052-31870-21/6684923)€ 50.18
Borgmoer M5 (oud 949566z)(10 Stuks )
143949566Borgmoer M5 (oud 949566z)(10 Stuks )€ 1.00
Niet meer leverbaar
1456684924Niet meer leverbaar
Fan
1466684925Fan€ 13.73
Ring
1476684926Ring€ 1.89
Tapschroef D5x20 Zwart
149302089Tapschroef D5x20 Zwart€ 1.02
Niet meer leverbaar
150A66A5660Niet meer leverbaar
Cover Spring Ass'y (oud 513-31870-80)
1516684928Cover Spring Ass'y (oud 513-31870-80)€ 20.06
Switch Cover (old 511-31870-20)
1526684929Switch Cover (old 511-31870-20)€ 2.08
Spring (old 790-31870-20)
1536684930Spring (old 790-31870-20)€ 2.08
Pin (old 0a53-31870-20)
1546684931Pin (old 0a53-31870-20)€ 8.30
Tapschroef D5x20 Zwart
155302089Tapschroef D5x20 Zwart€ 1.02
U-nut M8 (oud 991-74080-010)
1566684932U-nut M8 (oud 991-74080-010)€ 2.08
Shredder (old 128-31870-20)
1576684933Shredder (old 128-31870-20)€ 9.00
Hex.hole Bolt M5x35 (oud 990-51050-353)
1586684934Hex.hole Bolt M5x35 (oud 990-51050-353)€ 2.08
Ring 5 (old 992-10050-062)
1596684834Ring 5 (old 992-10050-062)€ 2.08
Ventilatorhuis
1606696391Ventilatorhuis€ 692.12
Tank Dop Compleet
161A6698402Tank Dop Compleet€ 4.07
Tank Cap Chain
162A6698732Tank Cap Chain€ 1.16
Niet meer leverbaar
1646684936Niet meer leverbaar
Starter Pulley (oud 798-03045-20)
1816684937Starter Pulley (oud 798-03045-20)€ 6.23
Recoil Starter Body Ass'y (old 762-03045-90)
1826684938Recoil Starter Body Ass'y (old 762-03045-90)€ 22.70
SET SCREW (OLD 839-03045-20)
1836684679SET SCREW (OLD 839-03045-20)€ 2.08
Pulley Stay (oud 771-03045-20)
1846684939Pulley Stay (oud 771-03045-20)€ 2.08
Swing Arm (oud 777-03045-20)
1856684940Swing Arm (oud 777-03045-20)€ 2.08
Starter Rope Reel (old 774-03045-20)
1866684941Starter Rope Reel (old 774-03045-20)€ 6.23
Recoil Spring (old 779-03045-20)
1876684942Recoil Spring (old 779-03045-20)€ 9.10
Rope 3.0x800 (old 783-03045-20)
1886684943Rope 3.0x800 (old 783-03045-20)€ 4.15
Recoil Starter Body Comp.(oud 772-03045-80)
1896684944Recoil Starter Body Comp.(oud 772-03045-80)€ 16.69
Starthendel
1906684680Starthendel€ 2.08
Hex.hole Bolt 4x15/ps (old 994-63040-154)
1916684682Hex.hole Bolt 4x15/ps (old 994-63040-154)€ 2.08
Starter Pulley
193A6696471Starter Pulley€ 4.94
Recoil Starter Body Ass'y
1946696572Recoil Starter Body Ass'y€ 9.87
Set Screw (old 839-02010-20/6693638)
1956693633Set Screw (old 839-02010-20/6693638)€ 1.11
Starter Rope Reel (old 774-03045-20)
1966684941Starter Rope Reel (old 774-03045-20)€ 6.23
Recoil Spring (old 780-06097-20/6697591)
1976684675Recoil Spring (old 780-06097-20/6697591)€ 11.18
Recoil Starter Body Comp.(oud 772-03045-80)
1986684944Recoil Starter Body Comp.(oud 772-03045-80)€ 16.69
Starter Rope (old 783-06097-20/6693174)
1996693168Starter Rope (old 783-06097-20/6693174)€ 2.24
Starthendel
2006693227Starthendel€ 3.19
Starter Pulley Ass'y (old 798-0651h-90)
2016684681Starter Pulley Ass'y (old 798-0651h-90)€ 12.78
Recoil Starter Ass'y (old 762-0735a-90)
202A6692993Recoil Starter Ass'y (old 762-0735a-90)€ 23.43
Cam Plate
203A6699996Cam Plate€ 2.47
Dumper Spring (old 758-0651h-20)
2046684677Dumper Spring (old 758-0651h-20)€ 8.30
Starter Rope Reel
205A6699997Starter Rope Reel€ 8.14
Recoil Starter Body Comp (old 772-0735a-80) New
2066693041Recoil Starter Body Comp (old 772-0735a-80) New€ 8.57
Starter Rope 3.5x860 (old 783-0720f-20/6697590)
2076684674Starter Rope 3.5x860 (old 783-0720f-20/6697590)€ 4.15
Cam Plate Ass'y
2096699691Cam Plate Ass'y€ 5.90
Combi Box Spanner 13x19 Plus (old 829-20000-80)
5016684979Combi Box Spanner 13x19 Plus (old 829-20000-80)€ 4.15
Er bevinden zich 0 artikelen in uw winkelwagen.
