Hier vindt u alle beschikbare onderdelen en tekeningen van de 'Makita HM1200K'. Vanaf hier kunt u direct alle gewenste onderdelen bestellen. Vele onderdelen moeten bij de fabrikant besteld worden, dit duurt afhankelijk van het merk, één tot vier weken. Alle informatie die we hebben, staat op onze website, wij kunnen u geen advies geven over wat u nodig heeft, daarvoor zult u de machine ter reparatie in moeten leveren. Let bij het bestellen op het volgende:
Tekeningen van de Makita HM1200K
Onderdelen lijst van de Makita HM1200K
| Pos. | Omschrijving | Prijs excl. BTW | Prijs incl. BTW | |
| Getoonde prijzen zijn inclusief btw | ||||
| Slaghuis | ||||
| 001 | 151310-9 | 141.54 | 171.26 | |
| Inbusbout M8x30 | ||||
| 002 | 922452-4 | 0.83 | 1.00 | |
| Veerring M8 | ||||
| 003 | 942201-3 | 0.83 | 1.00 | |
| O-ring 56 | ||||
| 004 | 213655-4 | 1.72 | 2.08 | |
| Zwevende zuiger | ||||
| 005 | 321732-9 | 20.76 | 25.12 | |
| Zuigerveer 40 | ||||
| 006* | 412049-2 | 16.07 | 19.44 | |
| Binnenring 36 | ||||
| 007* | 341862-0 | 4.08 | 4.94 | |
| Zuigerveer 40 | ||||
| 008* | 412049-2 | 16.07 | 19.44 | |
| Binnenring 36 | ||||
| 009* | 341862-0 | 4.08 | 4.94 | |
| Pen 10 | ||||
| 010 | 256120-0 | 2.80 | 3.39 | |
| Vuldop | ||||
| 012 | 414218-1 | 9.52 | 11.52 | |
| O-ring 71 | ||||
| 013 | 213754-2 | 2.08 | 2.52 | |
| Drijfstang | ||||
| 014 | 315419-3 | 19.80 | 23.96 | |
| Naaldlager 1516 | ||||
| 015 | 212208-6 | 14.23 | 17.22 | |
| Krukas | ||||
| 016 | 152180-9 | 27.35 | 33.09 | |
| Inlegspie 4 | ||||
| 017 | 254001-2 | 0.83 | 1.00 | |
| Borgring R-52 | ||||
| 018 | 962251-2 | 1.43 | 1.73 | |
| Kogellager 6304llu | ||||
| 019 | 211327-5 | 10.81 | 13.08 | |
| O-ring 53 | ||||
| 020 | 213656-2 | 1.21 | 1.46 | |
| Krukashuis | ||||
| 021 | 156863-3 | 73.52 | 88.96 | |
| Keerring 20 | ||||
| 022 | 213306-9 | 2.80 | 3.39 | |
| Tandwiel 50 | ||||
| 023 | 221701-9 | 39.92 | 48.30 | |
| Kogellager 6202llb | ||||
| 024 | 211228-7 | 7.44 | 9.00 | |
| Pen | ||||
| 025 | 256111-1 | 1.51 | 1.83 | |
| Tandwielhuis | ||||
| 026 | 157072-7 | 33.12 | 40.08 | |
| Zuiger | ||||
| 027 | 321441-0 | 28.85 | 34.91 | |
| Sluitring 32 | ||||
| 028 | 267059-2 | 11.68 | 14.13 | |
| Kunststof ring 33 | ||||
| 029 | 261069-1 | 5.22 | 6.32 | |
| Sluitring 33 | ||||
| 030 | 253976-2 | 7.80 | 9.44 | |
| Slagstuk | ||||
| 031 | 322256-8 | 35.99 | 43.55 | |
| O-ring 32 | ||||
| 032* | 213468-3 | 7.44 | 9.00 | |
| X-ring 28 | ||||
| 033* | 213428-5 | 17.90 | 21.66 | |
| O-ring 50 | ||||
| 034 | 213604-1 | 1.72 | 2.08 | |
| Beitelgeleider | ||||
| 035 | 321932-1 | 100.32 | 121.39 | |
| Gereedschapklem | ||||
| 036 | 331132-5 | 17.90 | 21.66 | |
| Veerring M8 | ||||
| 037 | 942201-3 | 0.83 | 1.00 | |
| Inbusbout M8x30 | ||||
| 038 | 922452-4 | 0.83 | 1.00 | |
| Drukveer 15 | ||||
| 039 | 231281-7 | 0.83 | 1.00 | |
| Zeskant moer 8x13 | ||||
| 041 | 252046-4 | 0.83 | 1.00 | |
| Zeskant bout 8x150 | ||||
| 042 | 265439-6 | 2.80 | 3.39 | |
| Handgreep basis 48 | ||||
| 045 | 416397-1 | 2.80 | 3.39 | |
| Zijhandgreep | ||||
| 048 | 417003-1 | 16.13 | 19.52 | |
| Handgreep opvulbus | ||||
| 048A | 417002-3 | 1.43 | 1.73 | |
| Keerring | ||||
| 050 | 331180-4 | 3.65 | 4.42 | |
| O-ring 35 | ||||
| 051 | 213460-9 | 1.21 | 1.46 | |
| Kogellager 6202llb | ||||
| 052 | 211228-7 | 7.44 | 9.00 | |
| Stofafdichting 15 | ||||
| 053 | 213202-1 | 1.21 | 1.46 | |
| Waaier 94 | ||||
| 054 | 241638-4 | 7.80 | 9.44 | |
| Anker Hm1200-Hm1200K | ||||
| 055 | 514778-4 | 108.87 | 131.73 | |
| Isolatiering | ||||
| 056 | 681635-2 | 0.83 | 1.00 | |
| Kogellager 6200llb | ||||
| 057 | 211066-7 | 4.58 | 5.54 | |
| O-ring 30 | ||||
| 058 | 213406-5 | 1.21 | 1.46 | |
| Tussenplaat | ||||
| 059 | 410163-8 | 4.81 | 5.82 | |
| Schroef 5X45 * | ||||
| 060 | 911266-6 | 0.83 | 1.00 | |
| Veld Hm1200 Hr3850 A | ||||
| 061 | 528910-4 | 70.59 | 85.41 | |
| Naamplaat | ||||
| 063 | 855544-3 | 2.93 | 3.55 | |
| Motorhuis | ||||
| 064 | 159034-1 | 39.89 | 48.27 | |
| Koolborstelhouderdop | ||||
| 065 | 643650-4 | 0.83 | 1.00 | |
| Koolborstel set Cb-155 | ||||
| 066* | 181048-2 | 9.52 | 11.52 | |
| Achterdeksel | ||||
| 067 | 284055-5 | 11.32 | 13.70 | |
| Veerring 5MM DLS211 | ||||
| 068 | 253427-5 | 0.83 | 1.00 | |
| Inbusbout 5x16 | ||||
| 069 | 922221-3 | 0.83 | 1.00 | |
| Inbusbout M6x50 | ||||
| 070 | 922371-4 | 0.83 | 1.00 | |
| Sluitring 6x12mm | ||||
| 072 | 941151-9 | 0.83 | 1.00 | |
| Zeskant moer M6 | ||||
| 073 | 931302-2 | 0.83 | 1.00 | |
| Veerring 6 A | ||||
| 074 | 253903-9 | 0.83 | 1.00 | |
| Sluitring 6x12mm | ||||
| 075 | 941151-9 | 0.83 | 1.00 | |
| Schroef 5x25 | ||||
| 076 | 911243-8 | 0.83 | 1.00 | |
| Handgreep | ||||
| 077 | 182077-8 | 17.90 | 21.66 | |
| Schroef 4X16 A | ||||
| 078 | 911526-6 | 0.83 | 1.00 | |
| Schakelaar Sw-52 | ||||
| 079 | 651145-3 | 26.11 | 31.59 | |
| Stofkap v schakelaar | ||||
| 080 | 421265-5 | 2.44 | 2.95 | |
| Condensator | ||||
| 081 | 645253-0 | 4.58 | 5.54 | |
| Sponsrubber | ||||
| 082 | 685700-9 | 0.83 | 1.00 | |
| Inbusbout M6X14 A | ||||
| 083 | 922316-2 | 0.83 | 1.00 | |
| Veerring 6 A | ||||
| 084 | 253903-9 | 0.83 | 1.00 | |
| Inbusbout M6x25 | ||||
| 085 | 265914-2 | 1.06 | 1.28 | |
| Veerring 6 A | ||||
| 086 | 253903-9 | 0.83 | 1.00 | |
| Beugel | ||||
| 087 | 343755-7 | 5.22 | 6.32 | |
| Handgreep | ||||
| 088 | 182077-8 | 17.90 | 21.66 | |
| Borstbout | ||||
| 089 | 321210-9 | 1.72 | 2.08 | |
| Kabeltule 10-90 | ||||
| 090 | 682505-8 | 1.72 | 2.08 | |
| Netsnoer 2x1.50 4.0mtr | ||||
| 091 | 695123-3 | 21.70 | 26.26 | |
| Klemstrip | ||||
| 092 | 687031-2 | 0.83 | 1.00 | |
| Schroef 4x18 | ||||
| 093 | 911133-5 | 0.83 | 1.00 | |
| Rubber ring 9 | ||||
| 096 | 262051-3 | 0.83 | 1.00 | |
| Rubber Ring 9 | ||||
| 097 | 262052-1 | 0.83 | 1.00 | |
| Bus | ||||
| 098 | 257636-8 | 2.08 | 2.52 | |
| Handgreepveer 48 nieuw | ||||
| 099 | 344560-5 | 4.08 | 4.94 | |
| Knop M8 | ||||
| 100 | 252640-2 | 5.88 | 7.11 | |
| Handgreep basis 48 | ||||
| 101 | 416397-1 | 2.80 | 3.39 | |
