Hier vindt u alle beschikbare onderdelen en tekeningen van de 'Metabo 01751002 ( KFM9-3RF )'. Vanaf hier kunt u direct alle gewenste onderdelen bestellen. Vele onderdelen moeten bij de fabrikant besteld worden, dit duurt afhankelijk van het merk, één tot vier weken. Alle informatie die we hebben, staat op onze website, wij kunnen u geen advies geven over wat u nodig heeft, daarvoor zult u de machine ter reparatie in moeten leveren. Let bij het bestellen op het volgende:
Tekeningen van de Metabo 01751002 ( KFM9-3RF )
Onderdelen lijst van de Metabo 01751002 ( KFM9-3RF )
Pos. | Omschrijving | Prijs excl. BTW | Prijs incl. BTW | |
Getoonde prijzen zijn inclusief btw | ||||
Anker compl.,230 V | ||||
1 | 310011830 | 67.33 | 81.47 | |
Veld 230 V | ||||
2 | 311009770 | 48.48 | 58.66 | |
Kabel m. CEE-stekker | ||||
3 | 344499650 | 18.80 | 22.75 | |
Kabelbescherming | ||||
4 | 344097360 | 1.55 | 1.88 | |
Kabelklem | ||||
5 | 343362490 | 1.67 | 2.02 | |
Schroef | ||||
6 | 141117060 | 1.67 | 2.02 | |
Koolborstelhouder compl. uitsch.,230V | ||||
7 | 316046890 | 11.74 | 14.21 | |
Schakelaar m. elektronica,230 V/50-60 Hz | ||||
9 | 316050300 | 43.15 | 52.21 | |
Verbindingsdraad compl. | ||||
10 | 344498880 | 1.55 | 1.88 | |
Motorhuis | ||||
11 | 315013660 | 11.74 | 14.21 | |
Schakelstang | ||||
12 | 343430940 | 1.55 | 1.88 | |
Schakelschuif ,H/L | ||||
13 | 343397810 | 1.55 | 1.88 | |
Groefkogellager,6x19x6 | ||||
14 | 143115690 | 2.28 | 2.76 | |
Bus rubber | ||||
15 | 344097870 | 1.55 | 1.88 | |
Luchtgeleidingsschijf | ||||
16 | 343436590 | 2.28 | 2.76 | |
Kogellager, 8X 22X 7 | ||||
17 | 143115060 | 5.87 | 7.10 | |
Motorkap 2-delig | ||||
18 | 343432950 | 8.89 | 10.76 | |
Schroef | ||||
19 | 141113180 | 1.55 | 1.88 | |
Afstandsbus | ||||
20 | 341006070 | 11.74 | 14.21 | |
Tussenflens groen | ||||
21 | 343431740 | 10.38 | 12.56 | |
Schaalverdeling | ||||
30 | 341211520 | 32.27 | 39.05 | |
Verstelring | ||||
31 | 341211530 | 100.74 | 121.90 | |
Huis | ||||
32 | 341211540 | 80.81 | 97.78 | |
Drukveer | ||||
34 | 342004080 | 16.25 | 19.66 | |
Grondplaat | ||||
35 | 341211550 | 113.82 | 137.72 | |
Typeplaatje | ||||
37 | 338068190 | 1.55 | 1.88 | |
Aanduidingsplaatje waarschuwing | ||||
38 | 338127220 | 3.71 | 4.49 | |
Geen informatie beschikbaar, niet bestelbaar | ||||
40 | 399999990 | |||
Aanduidingsplaatje | ||||
41 | 338128450 | 1.67 | 2.02 | |
Parallelgeleider compl. | ||||
42 | 316062870 | 121.19 | 146.64 | |
Tandwielhuis compl. | ||||
43 | 316046070 | 24.23 | 29.32 | |
Schroef | ||||
44 | 141116980 | 1.55 | 1.88 | |
O-ring | ||||
45 | 143195320 | 1.55 | 1.88 | |
Zeskantmoer | ||||
46 | 341102140 | 1.55 | 1.88 | |
Vaste lagerdeksel | ||||
47 | 315417490 | 1.55 | 1.88 | |
Lensschroef | ||||
48 | 141124170 | 1.55 | 1.88 | |
Lensschroef | ||||
49 | 141124090 | 1.55 | 1.88 | |
Opvulring | ||||
50 | 339011860 | 1.55 | 1.88 | |
Tandwiel set | ||||
51 | 316093360 | 26.95 | 32.61 | |
Flens compl. | ||||
52 | 316093280 | 113.82 | 137.72 | |
Groefkogellager | ||||
53 | 320054130 | 12.23 | 14.80 | |
Borgring | ||||
54 | 141180390 | 1.67 | 2.02 | |
Spil compl. | ||||
55 | 316093290 | 348.32 | 421.47 | |
Groefkogellager | ||||
56 | 320054160 | 43.15 | 52.21 | |
Borgring | ||||
57 | 141180130 | 1.55 | 1.88 | |
Aanloopring compl. | ||||
58 | 316093300 | 21.64 | 26.18 | |
HOOGTEVERSTELLING COMPLEET | ||||
59 | 316093370 | 242.14 | 292.99 | |
O-ring | ||||
60 | 143191930 | 1.67 | 2.02 | |
Veerring | ||||
62 | 339007910 | 3.02 | 3.65 | |
Veerring | ||||
63 | 339007920 | 3.02 | 3.65 | |
Adapter links | ||||
65 | 339137590 | 5.87 | 7.10 | |
Adapter rechts | ||||
66 | 339137600 | 5.87 | 7.10 | |
Rustplaat | ||||
67 | 341071240 | 12.23 | 14.80 | |
Beugelgreep compl. | ||||
68 | 343399690 | 18.80 | 22.75 | |
Ring | ||||
69 | 141153390 | 1.55 | 1.88 | |
Cilinderkopschroef | ||||
70 | 141114590 | 1.67 | 2.02 | |
Vleugelmoer | ||||
71 | 341111870 | 2.28 | 2.76 | |
Inbussleutel | ||||
72 | 344161510 | 1.67 | 2.02 | |
Borgring cpl. | ||||
74 | 316096620 | 13.48 | 16.31 | |
Schroef compl. | ||||
81 | 316093380 | 3.02 | 3.65 | |
Spilstop | ||||
82 | 316040610 | 3.02 | 3.65 | |
Waaier m. stofbescherming | ||||
85 | 316051700 | 5.18 | 6.27 | |
Koolborstelset uitsch. | ||||
86 | 316046900 | 11.74 | 14.21 | |
Stelschroef | ||||
88 | 141124550 | 1.55 | 1.88 | |
Schroef,Set | ||||
89 | 341723160 | 32.27 | 39.05 | |
Aanloopring compl. | ||||
92 | 316066080 | 32.27 | 39.05 | |
Tube vet 100 gr. | ||||
880 | 344130920 | 37.65 | 45.56 | |
Geen informatie beschikbaar, niet bestelbaar | ||||
1001 | 338505710 |
