Hier vindt u alle beschikbare onderdelen en tekeningen van de 'Milwaukee 4000390187 ( HD2E13R )'. Vanaf hier kunt u direct alle gewenste onderdelen bestellen. Vele onderdelen moeten bij de fabrikant besteld worden, dit duurt afhankelijk van het merk, één tot vier weken. Alle informatie die we hebben, staat op onze website, wij kunnen u geen advies geven over wat u nodig heeft, daarvoor zult u de machine ter reparatie in moeten leveren. Let bij het bestellen op het volgende:
Tekeningen van de Milwaukee 4000390187 ( HD2E13R )
Onderdelen lijst van de Milwaukee 4000390187 ( HD2E13R )
| Pos. | Omschrijving | Prijs excl. BTW | Prijs incl. BTW | |
| Getoonde prijzen zijn inclusief btw | ||||
| RATING PLATE | ||||
| 0003 | 4931390194 | 1.80 | 2.18 | |
| CONNECTION CABLE | ||||
| 0004 | 4931622543 | 12.60 | 15.25 | |
| TYPE PLATE | ||||
| 0005 | 4931378806 | 5.40 | 6.53 | |
| ELECTRIC FIELD | ||||
| 0105 | 4931442724 | 30.80 | 37.27 | |
| ARMATURE | ||||
| 0106 | 4931426272 | 30.72 | 37.17 | |
| FAN | ||||
| 0107 | 4931302487 | 4.49 | 5.43 | |
| GROOVED BALL BEAR, | ||||
| 0108 | 4931368037 | 5.40 | 6.53 | |
| BALL BEARING | ||||
| 0109 | 4931901253 | 9.00 | 10.89 | |
| Niet meer leverbaar, geen vervanging | ||||
| 0110 | 4931267945 | |||
| BEARING COVER | ||||
| 0111 | 4931267585 | 4.49 | 5.43 | |
| CHOKING COIL | ||||
| 0112 | 4931623023 | 4.49 | 5.43 | |
| CHOKING COIL | ||||
| 0113 | 4931622291 | 4.49 | 5.43 | |
| BRUSH HOLDER | ||||
| 0114 | 4931271665 | 4.49 | 5.43 | |
| BRUSH HOLDER | ||||
| 0115 | 4931622292 | 5.40 | 6.53 | |
| BRUSH HOLDER | ||||
| 0116 | 4931315039 | 5.40 | 6.53 | |
| BRUSH HOLDER (2 benodigd) | ||||
| 0116 | 4931271678 | 3.00 | 3.63 | |
| CABLE COLLAR | ||||
| 0117 | 4931256500 | 5.40 | 6.53 | |
| CABLE | ||||
| 0118 | 4931253699 | 4.49 | 5.43 | |
| WIRE | ||||
| 0119 | 4931622262 | 4.49 | 5.43 | |
| SWITCH BOARD | ||||
| 0135 | 4931382377 | 17.42 | 21.08 | |
| SCREW | ||||
| 0136 | 4931621772 | 1.80 | 2.18 | |
| Capacitor | ||||
| 0140 | 4931622384 | 4.49 | 5.43 | |
| DRILL SPINDLE | ||||
| 0203 | 4931409811 | 12.60 | 15.25 | |
| SLEEVE | ||||
| 0204 | 4931267415 | 4.49 | 5.43 | |
| BALL BEARING | ||||
| 0205 | 4931891058 | 9.00 | 10.89 | |
| PERCUSSION SLEEVE | ||||
| 0206 | 4931267571 | 3.60 | 4.36 | |
| SEAL RING | ||||
| 0207 | 4931267522 | 5.40 | 6.53 | |
| LOCKING RING | ||||
| 0208 | 4931890311 | 5.40 | 6.53 | |
| DISC | ||||
| 0209 | 4931621647 | 1.80 | 2.18 | |
| DRILL SPINDLE WHEEL | ||||
| 0210 | 4931426230 | 9.00 | 10.89 | |
| SHIFT RING COMPL, | ||||
| 0211 | 4931307130 | 15.84 | 19.17 | |
| DRILL SPINDLE WHEEL | ||||
| 0212 | 4931267596 | 19.01 | 23.00 | |
| DISC | ||||
| 0213 | 4931621679 | 5.40 | 6.53 | |
| SWITCH LEVER | ||||
| 0214 | 4931339525 | 5.40 | 6.53 | |
| RETAINING SPRING | ||||
| 0215 | 4931307118 | 5.40 | 6.53 | |
| SWITCH LEVER | ||||
| 0216 | 4931267576 | 5.40 | 6.53 | |
| PIN | ||||
| 0217 | 4931621731 | 5.40 | 6.53 | |
| DISC | ||||
| 0218 | 4931621715 | 5.40 | 6.53 | |
| CAP | ||||
| 0219 | 4931267591 | 4.49 | 5.43 | |
| PIN | ||||
| 0220 | 4931621770 | 5.40 | 6.53 | |
| REDUCTION GEAR | ||||
| 0221 | 4931267597 | 30.10 | 36.42 | |
| PIN | ||||
| 0222 | 4931621732 | 5.40 | 6.53 | |
| GEAR BOX | ||||
| 0420 | 4931380479 | 49.10 | 59.41 | |
| BEARING END PLATE | ||||
| 0425 | 4931390198 | 22.18 | 26.84 | |
| HANDLE | ||||
| 0605 | 4931384539 | 17.42 | 21.08 | |
| Snelspanboorhouder 1.5 - 13 - / 20 / 2 sleeve with | ||||
| 0701 | 4932364267 | 60.46 | 73.16 | |
| Locking Screw | ||||
| 0801 | 4931401643 | 1.80 | 2.18 | |
| BOLT SET | ||||
| 1000 | 4931344833 | 14.40 | 17.42 | |
| HOUSING | ||||
| 1100 | 4931359606 | 25.34 | 30.66 | |
| MAINTENANCE SET | ||||
| 1200 | 4931344832 | 31.68 | 38.33 | |
| CARBON BRUSH SET | ||||
| 1201 | 4931361733 | 10.80 | 13.07 | |
