Hier vindt u alle beschikbare onderdelen en tekeningen van de 'Milwaukee 4000398602 ( K750S )'. Vanaf hier kunt u direct alle gewenste onderdelen bestellen. Vele onderdelen moeten bij de fabrikant besteld worden, dit duurt afhankelijk van het merk, één tot vier weken. Alle informatie die we hebben, staat op onze website, wij kunnen u geen advies geven over wat u nodig heeft, daarvoor zult u de machine ter reparatie in moeten leveren. Let bij het bestellen op het volgende:
Tekeningen van de Milwaukee 4000398602 ( K750S )
Onderdelen lijst van de Milwaukee 4000398602 ( K750S )
| Pos. | Omschrijving | Prijs excl. BTW | Prijs incl. BTW | |
| Getoonde prijzen zijn inclusief btw | ||||
| CONNECTION CABLE | ||||
| 0004 | 4931624585 | 17.42 | 21.08 | |
| RATING PLATE | ||||
| 0008 | 4931398605 | 1.73 | 2.09 | |
| STRIP-BAND | ||||
| 0010 | 4931398789 | 19.01 | 23.00 | |
| HANDLE | ||||
| 0011 | 4931398596 | 66.53 | 80.50 | |
| DAMPING ELEMENT | ||||
| 0012 | 4931449510 | 74.45 | 90.08 | |
| INSERT | ||||
| 0071 | 4931398672 | 33.26 | 40.24 | |
| MOTOR HOUSING | ||||
| 0100 | 4931398850 | 30.10 | 36.42 | |
| CASING | ||||
| 0100 | 4931398611 | 25.34 | 30.66 | |
| Electric Field | ||||
| 0105 | 4931442746 | 50.69 | 61.33 | |
| ARMATURE | ||||
| 0106 | 4931442688 | 95.04 | 115.00 | |
| FAN | ||||
| 0107 | 4931398185 | 4.49 | 5.43 | |
| Dust Seal | ||||
| 0110 | 4931398508 | 5.40 | 6.53 | |
| BEARING END PLATE | ||||
| 0111 | 4931426441 | 17.05 | 20.63 | |
| SCREW | ||||
| 0112 | 4931624541 | 1.80 | 2.18 | |
| LOCKING RING | ||||
| 0114 | 4931890311 | 5.40 | 6.53 | |
| SEAL RING | ||||
| 0115 | 4931398198 | 9.91 | 11.99 | |
| AIR DEFLECTOR RING | ||||
| 0116 | 4931398612 | 4.49 | 5.43 | |
| MOTOR CAP | ||||
| 0118 | 4931398613 | 15.29 | 18.50 | |
| SCREW D7500-1CE M6x60 T30 TAPT 2000 A2F | ||||
| 0119 | 4931624542 | 1.80 | 2.18 | |
| PAIR HANDLE SHELLS | ||||
| 0120 | 4931398208 | 20.59 | 24.91 | |
| SCREW | ||||
| 0121 | 4931364667 | 1.80 | 2.18 | |
| WIRE | ||||
| 0123 | 4931624263 | 5.40 | 6.53 | |
| SCREW | ||||
| 0124 | 4931624538 | 1.80 | 2.18 | |
| CABLE COLLAR | ||||
| 0125 | 4931256500 | 5.40 | 6.53 | |
| SCREW | ||||
| 0126 | 4931624538 | 1.80 | 2.18 | |
| Screw N874101-1 Shr H-k4x22 T15 | ||||
| 0129 | 4931624517 | 1.80 | 2.18 | |
| BRUSH HOLDER | ||||
| 0130 | 4931381694 | 5.40 | 6.53 | |
| Screw | ||||
| 0131 | 4931624504 | 1.80 | 2.18 | |
| ELECTRIC ELEMENT | ||||
| 0132 | 4931398673 | 39.60 | 47.92 | |
| LIGHT PIPE | ||||
| 0133 | 4931398114 | 5.40 | 6.53 | |
| Cable | ||||
| 0134 | 4931624681 | 5.40 | 6.53 | |
| SWITCH | ||||
| 0135 | 4931375454 | 19.01 | 23.00 | |
| PUSH-BUTTON | ||||
| 0136 | 4931398529 | 5.40 | 6.53 | |
| SHOCK ABSORBER | ||||
| 0140 | 4931398660 | 74.45 | 90.08 | |
| BRACKET | ||||
| 0141 | 4931398661 | 5.40 | 6.53 | |
| AVS-Rear Girder | ||||
| 0142 | 4931398665 | 5.40 | 6.53 | |
| AVS-COUNTER WEIGHT | ||||
| 0143 | 4931398662 | 9.00 | 10.89 | |
| PRESSURE SPRING | ||||
| 0144 | 4931398664 | 4.49 | 5.43 | |
| GUIDE BAR | ||||
| 0145 | 4931398663 | 9.00 | 10.89 | |
| NUT | ||||
| 0146 | 4931398666 | 4.49 | 5.43 | |
| BEARING | ||||
| 0156 | 4931398095 | 9.00 | 10.89 | |
| PROTECTION WASHER | ||||
| 0157 | 9170315810 | 1.80 | 2.18 | |
| BEARING BOLT | ||||
| 0158 | 4931398746 | 8.09 | 9.79 | |
| GEAR BOX | ||||
| 0200 | 4931409533 | 137.81 | 166.75 | |
| GEAR BOX INSULATION | ||||
| 0201 | 4931398624 | 15.84 | 19.17 | |
| GEAR BOX COVER | ||||
| 0212 | 4931426454 | 44.35 | 53.66 | |
| SCREW | ||||
| 0214 | 4931624555 | 1.80 | 2.18 | |
| REPAIR KIT | ||||
| 0225 | 4931432431 | 147.31 | 178.25 | |
| Driver | ||||
| 0233 | 4931426171 | 60.19 | 72.83 | |
| CRANK WHEEL | ||||
| 0236 | 4931409601 | 42.77 | 51.75 | |
| Niet meer leverbaar, geen vervanging | ||||
| 0237 | 4931398839 | |||
| SPINDLE SLEEVE | ||||
| 0238 | 4931455234 | 156.82 | 189.75 | |
| BACK-PRESSURE RING | ||||
| 0239 | 4931398031 | 5.40 | 6.53 | |
| DISC | ||||
| 0241 | 4931398032 | 9.00 | 10.89 | |
| CORE LIFTER RING | ||||
| 0241 | 4931398642 | 9.00 | 10.89 | |
| PERC, BODY W SEAL | ||||
| 0246 | 4931455749 | 44.35 | 53.66 | |
| Perc. Body W Seal | ||||
| 0246 | 4931455434 | 41.18 | 49.83 | |
| Piston Compl. | ||||
| 0258 | 4931398792 | 34.85 | 42.17 | |
| SET COLLAR | ||||
| 0268 | 4931398078 | 5.40 | 6.53 | |
| Needle Bearing | ||||
| 0270 | 4931621847 | 9.00 | 10.89 | |
| REPAIR KIT | ||||
| 0272 | 4931432431 | 147.31 | 178.25 | |
| SPINDLE BEVEL GEAR | ||||
| 0272 | 4931432188 | 31.68 | 38.33 | |
| ADJUSTING PIECE | ||||
| 0273 | 4931398154 | 5.40 | 6.53 | |
| LOCKING PLATE | ||||
| 0274 | 4931398075 | 5.40 | 6.53 | |
| SWITCH | ||||
| 0275 | 4931398626 | 10.80 | 13.07 | |
| Ring | ||||
| 0282 | 4931624479 | 5.40 | 6.53 | |
| Thrust Collar | ||||
| 0288 | 4931398749 | 6.31 | 7.64 | |
| Disc | ||||
| 0290 | 4931624499 | 5.40 | 6.53 | |
| LATCH PLATE | ||||
| 0291 | 4931398658 | 5.40 | 6.53 | |
| SCREW | ||||
| 0292 | 4931624236 | 1.80 | 2.18 | |
| THRUST PIECE | ||||
| 0293 | 4931398097 | 4.49 | 5.43 | |
| WASHER | ||||
| 0294 | 4931455748 | 1.80 | 2.18 | |
| PRESSURE SPRING | ||||
| 0295 | 4931398099 | 4.49 | 5.43 | |
| DISC | ||||
| 0297 | 4931624535 | 5.40 | 6.53 | |
| Sleeve | ||||
| 0305 | 4931398744 | 5.40 | 6.53 | |
| Locking Lever | ||||
| 0306 | 4931426248 | 5.40 | 6.53 | |
| Pressure Spring | ||||
| 0309 | 4931398856 | 5.40 | 6.53 | |
| Reparatieset | ||||
| 0310 | 4931426013 | 12.60 | 15.25 | |
| REPAIR KIT | ||||
| 0400 | 4931432431 | 147.31 | 178.25 | |
| ARMATURE ASSEMBLY | ||||
| 0406 | 4931449973 | 167.90 | 203.16 | |
| REPAIR KIT | ||||
| 0420 | 4931455736 | 351.65 | 425.50 | |
| CARRYING CASE | ||||
| 0700 | 4931402576 | 99.79 | 120.75 | |
| Handle | ||||
| 0705 | 4931398676 | 87.12 | 105.42 | |
| MAINTENANCE SET | ||||
| 1200 | 4931398607 | 201.17 | 243.42 | |
| CARBON BRUSH SET | ||||
| 1201 | 4931398132 | 15.84 | 19.17 | |
| O-RING N874701 26X3 | ||||
| 1204 | 4931622166 | 1.80 | 2.18 | |
| PROTECTING COVER | ||||
| 1205 | 4931393422 | 5.40 | 6.53 | |
| DAMPING ELEMENT | ||||
| 1207 | 4931398748 | 5.40 | 6.53 | |
| SEALING SLEEVE | ||||
| 1208 | 4931398101 | 5.40 | 6.53 | |
| Rubber Sleeve | ||||
| 1209 | 4931398085 | 3.60 | 4.36 | |
| Seal Ring | ||||
| 1210 | 4931624440 | 5.40 | 6.53 | |
| Snap Die | ||||
| 1212 | 4931398639 | 50.69 | 61.33 | |
| O-ring (fkm) | ||||
| 1213 | 4931398297 | 1.80 | 2.18 | |
| SEAL | ||||
| 1216 | 4931398539 | 5.40 | 6.53 | |
| Sleeve | ||||
| 1219 | 4931624621 | 5.40 | 6.53 | |
| Core Lifter Ring | ||||
| 1220 | 4931398033 | 5.40 | 6.53 | |
| RING | ||||
| 1221 | 4931398073 | 5.40 | 6.53 | |
| Spring Ring | ||||
| 1222 | 9170319040 | 1.80 | 2.18 | |
| Niet meer leverbaar, geen vervanging | ||||
| 1223 | 4931398068 | |||
| Seal Retainer | ||||
| 1224 | 4931398790 | 11.69 | 14.14 | |
| Interlock Disc | ||||
| 1225 | 4931398080 | 5.40 | 6.53 | |
| SEAL RING | ||||
| 1226 | 4931624495 | 5.40 | 6.53 | |
| Rubber Cap | ||||
| 1227 | 4931398064 | 6.31 | 7.64 | |
| Geen informatie beschikbaar, niet bestelbaar | ||||
| 1228 | 4931271824 | |||
| Reparatieset | ||||
| 1230 | 4931426013 | 12.60 | 15.25 | |
| Washer | ||||
| 1231 | 4931398298 | 1.80 | 2.18 | |
| WASHER | ||||
| 1232 | 4931624586 | 1.80 | 2.18 | |
| Grooved Ball Bear. | ||||
| 1234 | 4931398189 | 5.40 | 6.53 | |
| Ball Bearing | ||||
| 1235 | 4931341741 | 9.00 | 10.89 | |
| Magnetic Disc | ||||
| 1236 | 4931426570 | 5.40 | 6.53 | |
| Stop Washer | ||||
| 1238 | 4931409781 | 17.11 | 20.70 | |
| RING | ||||
| 1239 | 4931398644 | 5.40 | 6.53 | |
| Driver | ||||
| 1240 | 4931398643 | 5.40 | 6.53 | |
